翻刻
大-桅長￣サ九-丈二-尺。圍九-尺。
頭-桅長￣サ七-丈二-尺。圍七-尺。
櫓-二￣ツ。長￣サ四-丈。寬￣サ二-尺三-寸。
椗大-小各-二￣ツ。大-者長￣サ二-丈七-尺。小-者長￣サ二-丈四-尺。皆
寬￣サ八-寸。及￣ヒ七-寸。形如＿二个-字＿一￣ノ。皆以＿二鐵-力-木＿一￣ヲ爲＿レ￣ル之￣ヲ。椗-上￣ノ棕-
索二-條。長￣サ一-百-托。圍一-尺五-寸。《割書：按￣ニ字-書￣ニ。碇￣ハ錘＿レ￣スル舟￣ヲ石￣ナリ也。｜與＿レ矴同。無＿二椗-字＿一。今以》
《割書：＿レ木￣ヲ爲＿レ之。故￣ニ｜俗-字從＿レ￣フ木￣ニ。》
大-桅￣ノ蓆-篷寬￣サ五-丈二-尺。長￣サ五-丈三-尺。轆-轤-索三-條。長￣サ
三-十-五-托。圍一-尺二-寸。
繚-母-索二-條。長￣サ一-十-五-托。圍一-尺五-寸。
頭-桅￣ノ蓆-篷寬￣サ二-丈二-尺。長￣サ二-丈八-尺。
大-桅-頂￣ノ篷￣ヲ名＿二￣ク頭-巾-頂＿一￣ト。惟官舶始￣テ用＿レ￣ユ之￣ヲ。商-船不＿レ得＿レ用￣ヿヲ。長￣サ
五-丈四-尺。寬￣サ五-丈。《割書：徐-兢￣カ錄￣ニ云。大-檣￣ノ之巓。加＿二小-帆十-｜幅＿一￣ヲ。謂＿二之￣ヲ野-狐-帆＿一￣ト。殆-卽頭-巾-頂￣ナリ也。》
大-桅￣ノ下￣ノ布篷￣ヲ名＿二￣ク篷-裙＿一￣ト。長￣サ六-尺。寬￣サ一-丈五-尺。
頭-桅-上布-篷￣ヲ名＿二￣ク頭-幞＿一￣ト。上尖￣リ下方￣ナリ。三-角￣ノ形。長￣サ三-丈。下￣ノ濶￣サ
二-丈八-尺。
挿-花布-篷長￣サ四-丈八-尺。寬￣サ三-丈四-尺。
挿-花下￣ノ布-篷￣ヲ名＿二￣ク挿-花-褲＿一￣ト。長￣サ六-尺。寬￣サ一-丈五-尺。
現代語訳
大桅の長さは九丈二尺。周囲九尺。
頭桅の長さは七丈二尺。周囲七尺。
櫓二つ。長さ四丈。幅二尺三寸。
錨は大小各二つ。大きい物は長さ二丈七尺。小さい物は長さ二丈四尺。皆幅八寸及び七寸。形は个の字のような形。皆鉄力木で作る。錨の上の棕索二条。長さ百托。周囲一尺五寸。《字書によると、碇は舟を沈める石である。矴と同じ。椗の字は無い。今木で作るので、俗字は木偏に従う。》
大桅の蓆篷は幅五丈二尺。長さ五丈三尺。轆轤索三条。長さ三十五托。周囲一尺二寸。
繚母索二条。長さ十五托。周囲一尺五寸。
頭桅の蓆篷は幅二丈二尺。長さ二丈八尺。
大桅頂の篷を頭巾頂と名づける。ただ官船のみが初めてこれを用いる。商船は用いることを得ず。長さ五丈四尺。幅五丈。《徐兢の録に云う。大檣の頂に小帆十幅を加える。これを野狐帆と謂う。殆ど即ち頭巾頂である。》
大桅の下の布篷を篷裙と名づける。長さ六尺。幅一丈五尺。
頭桅上の布篷を頭幞と名づける。上は尖り下は方形。三角の形。長さ三丈。下の幅は二丈八尺。
挿花布篷は長さ四丈八尺。幅三丈四尺。
挿花の下の布篷を挿花褲と名づける。長さ六尺。幅一丈五尺。
英語訳
The main mast is nine zhang and two chi long, with a circumference of nine chi.
The foremast is seven zhang and two chi long, with a circumference of seven chi.
Two oars, each four zhang long and two chi and three cun wide.
Large and small anchors, two each. The large one is two zhang and seven chi long. The small one is two zhang and four chi long. All are eight cun and seven cun wide respectively. Shaped like the character "个". All made of ironwood. Two palm fiber ropes above the anchors. Length one hundred tuo. Circumference one chi and five cun. [According to dictionaries, "ding" refers to stones used to sink ships. Same as "zhen". There is no character "zhuo". Now made of wood, so the colloquial character follows the wood radical.]
The mat sail of the main mast is five zhang and two chi wide and five zhang and three chi long. Three windlass ropes. Length thirty-five tuo. Circumference one chi and two cun.
Two binding ropes. Length fifteen tuo. Circumference one chi and five cun.
The mat sail of the foremast is two zhang and two chi wide and two zhang and eight chi long.
The sail at the top of the main mast is called "turban top." Only official ships may use this for the first time. Merchant ships are not permitted to use it. Length five zhang and four chi. Width five zhang. [Xu Jing's record states: At the top of the main mast, ten small sails are added. This is called the "wild fox sail." This is probably the same as the turban top.]
The cloth sail below the main mast is called "sail skirt." Length six chi. Width one zhang and five chi.
The cloth sail above the foremast is called "head wrap." Pointed at the top and square at the bottom. Triangular in shape. Length three zhang. Width at the bottom is two zhang and eight chi.
The decorative cloth sail is four zhang and eight chi long and three zhang and four chi wide.
The cloth sail below the decorative sail is called "decorative trousers." Length six chi. Width one zhang and five chi.
